Customizing PersonalSettings (Personal Info) page not working #1404

beuko created 4 years ago

ABP Framework version: v4.3.1
UI type: Angular
DB provider: EF Core
Tiered (MVC) or Identity Server Separated (Angular): no / no
Exception message and stack trace:
Steps to reproduce the issue:

Hello. I am trying to add boolean field to Personal Setting (Personal info) in Angular UI. Field already exists in AbpUsers table.

I am following this guide https://docs.abp.io/en/abp/latest/UI/Angular/Component-Replacement.

First I installed module @abp/ng.account with yarn so I can get eAccountComponents.PersonalSettings for replacing. After I installed module I got bunch of errors in others components (only html classes)...

After that I created my custom component and added replaceble logic to AppComponent

import { Component } from '@angular/core';
import { CustomPersonalSettingsComponentComponent } from './custom-personal-settings-component/custom-personal-settings-component.component';
import { ReplaceableComponentsService } from '@abp/ng.core';
import { eAccountComponents } from '@abp/ng.account';

@Component({
  selector: 'app-root',
  template: `
    <abp-loader-bar></abp-loader-bar>
    <abp-dynamic-layout></abp-dynamic-layout>
  `,
})
export class AppComponent {

  constructor(
    private replaceableComponents: ReplaceableComponentsService, // injected the service
  ) {
    this.replaceableComponents.add({
      component: CustomPersonalSettingsComponentComponent,
      key: eAccountComponents.PersonalSettings,
    });
  }

}

After adding imports, I got error that abp-dynamics-layout is not a known element...

Even with all that errors, my project compiled successfully and I can use all my broken components (html). When I go to Personal info, it still show default component, not mine...

Anyone know why I got these errors in html after installing @abp/ng.account and why PersonalInfo replacing is not working? If I try and replace Manage profile component it works...

Go to accepted answer

beuko created 4 years ago

I fixed problems with html components.

First I cleared cache, then deleted node_modules folder and reinstalled all modules with yarn install... Now I dont have any errors with html, but replacing PageSettings component still not working...

beuko created 4 years ago

Any answer to this?

Mehmet created 4 years ago

Hi,

Please follow the steps below to replace personal settings component:

Run the following command to generate account module:

yarn ng generate module account

Run command below to generate a component called CustomPersonalSettings:

yarn ng generate component account/custom-personal-settings --skip-tests --inline-style

Replace the generated src/account/account.module.ts content with following:

import { NgModule } from '@angular/core';
import { AccountPublicModule } from '@volo/abp.ng.account/public';
import { SharedModule } from '../shared/shared.module';
import { CustomPersonalSettingsComponent } from './custom-personal-settings/custom-personal-settings.component';

@NgModule({
  declarations: [CustomPersonalSettingsComponent],
  imports: [AccountPublicModule.forChild({}), SharedModule],
})
export class AccountModule {}

Replace the generated src/account/custom-personal-settings/custom-personal-settings.component.ts content with following:

import { ConfigStateService, ProfileService, SubscriptionService } from '@abp/ng.core';
import { Confirmation, ConfirmationService, ToasterService } from '@abp/ng.theme.shared';
import { Component, EmbeddedViewRef, OnInit } from '@angular/core';
import { FormBuilder, FormGroup, Validators } from '@angular/forms';
import {
  AccountService,
  ManageProfileStateService,
  ProfileResponse,
} from '@volo/abp.ng.account/public';
import { Observable } from 'rxjs';
import { filter, tap } from 'rxjs/operators';

@Component({
  selector: 'app-custom-personal-settings',
  templateUrl: './custom-personal-settings.component.html',
  styles: [],
})
export class CustomPersonalSettingsComponent implements OnInit {
  storedProfile: ProfileResponse;

  profile$: Observable = this.manageProfileState.getProfile$();

  modalVisible = false;

  modalBusy: boolean = false;

  modalRef: EmbeddedViewRef;

  form: FormGroup;

  token: string = '';

  isEmailUpdateEnabled: boolean = true;
  isUserNameUpdateEnabled: boolean = true;

  showEmailVerificationBtn$ = this.manageProfileState.createStateStream(
    state => !state.hideEmailVerificationBtn
  );

  get userId(): string {
    return this.configState.getDeep('currentUser.id');
  }

  askForImmediatePhoneNumberVerification = () => {
    this.confirmationService
      .info('AbpAccount::DoYouWantToVerifyPhoneNumberMessage', 'AbpAccount::ConfirmYourPhoneNumber')
      .pipe(filter(status => status === Confirmation.Status.confirm))
      .subscribe(this.initPhoneNumberConfirmation);
  };

  checkPhoneNumberChanges = ({ phoneNumber }: ProfileResponse) => {
    if (phoneNumber && phoneNumber !== this.storedProfile?.phoneNumber) {
      this.askForImmediatePhoneNumberVerification();
    }
  };

  buildForm = (profile: ProfileResponse) => {
    this.form = this.fb.group({
      userName: [profile.userName, [Validators.required, Validators.maxLength(256)]],
      email: [profile.email, [Validators.required, Validators.email, Validators.maxLength(256)]],
      name: [profile.name || '', [Validators.maxLength(64)]],
      surname: [profile.surname || '', [Validators.maxLength(64)]],
      phoneNumber: [profile.phoneNumber || '', [Validators.maxLength(16)]],
    });
  };

  initPhoneNumberConfirmation = () => {
    this.accountService
      .sendPhoneNumberConfirmationToken({
        phoneNumber: this.form.value.phoneNumber,
        userId: this.userId,
      })
      .pipe(tap(() => (this.token = '')))
      .subscribe(this.openModal);
  };

  openModal = () => {
    this.modalVisible = true;
  };

  removeModal = () => {
    this.modalVisible = false;
  };

  setPhoneNumberAsConfirmed = () => {
    this.storedProfile.phoneNumberConfirmed = true;
  };

  constructor(
    private fb: FormBuilder,
    private accountService: AccountService,
    private toasterService: ToasterService,
    private confirmationService: ConfirmationService,
    private configState: ConfigStateService,
    private subscription: SubscriptionService,
    private manageProfileState: ManageProfileStateService,
    private profileService: ProfileService
  ) {}

  confirmPhoneNumber() {
    this.accountService
      .confirmPhoneNumber({ token: this.token, userId: this.userId })
      .pipe(tap(this.setPhoneNumberAsConfirmed), tap(this.removeModal))
      .subscribe(() => {
        this.toasterService.success('AbpAccount::Verified', '', { life: 5000 });
      });
  }

  sendEmailVerificationToken() {
    this.accountService
      .sendEmailConfirmationToken({
        appName: 'Angular',
        email: this.form.value.email,
        userId: this.userId,
      })
      .subscribe(() => {
        this.toasterService.success('AbpAccount::EmailConfirmationSentMessage', '', {
          messageLocalizationParams: [this.form.value.email],
        });

        this.manageProfileState.setHideEmailVerificationBtn(true);
      });
  }

  ngOnDestroy() {
    this.removeModal();
  }

  ngOnInit() {
    this.subscription.addOne(
      this.profile$.pipe(
        filter(Boolean),
        tap(profile => (this.storedProfile = profile)),
        tap(this.checkPhoneNumberChanges)
      ),
      this.buildForm
    );

    const settings = this.configState.getSettings();
    this.isEmailUpdateEnabled =
      (settings['Abp.Identity.User.IsEmailUpdateEnabled'] || '').toLowerCase() !== 'false';
    this.isUserNameUpdateEnabled =
      (settings['Abp.Identity.User.IsUserNameUpdateEnabled'] || '').toLowerCase() !== 'false';
  }

  submit() {
    if (this.form.invalid) return;

    const { phoneNumberConfirmed, ...profile } = this.form.value;

    this.profileService.update(profile).subscribe(res => {
      this.manageProfileState.setProfile(res);
      this.toasterService.success('AbpAccount::PersonalSettingsSaved', '', { life: 5000 });
    });
  }
}

Replace the generated src/account/custom-personal-settings/custom-personal-settings.component.html content with following:



    {{ 'AbpIdentity::DisplayName:UserName' | abpLocalization }} *




        {{ 'AbpIdentity::DisplayName:Name' | abpLocalization }}




        {{ 'AbpIdentity::DisplayName:Surname' | abpLocalization }}




    {{ 'AbpIdentity::DisplayName:Email' | abpLocalization }} *








    {{ 'AbpIdentity::DisplayName:PhoneNumber' | abpLocalization }}








    {{ 'AbpIdentity::Save' | abpLocalization }}




    {{ 'AbpAccount::Verify' | abpLocalization }}





          {{ 'AbpAccount::ConfirmationTokenSentMessage' | abpLocalization: form.value.phoneNumber }}


          {{
            'AbpAccount::PhoneConfirmationToken' | abpLocalization
          }}







      {{ 'AbpAccount::Cancel' | abpLocalization }}


      {{ 'AbpAccount::Save' | abpLocalization }}

Open src/app-routing.module.ts file modify account route like this:

  {
    path: 'account',
    loadChildren: () => import('./account/account.module').then(m => m.AccountModule),
  },

Open src/app.component.ts and replace the PersonalSettingsComponent as shown below:

import { Component, OnInit } from '@angular/core';
import {
  eAccountManageProfileTabNames,
  ManageProfileTabsService,
} from '@volo/abp.ng.account/public/config';
import { CustomPersonalSettingsComponent } from './account/custom-personal-settings/custom-personal-settings.component';

@Component({
  selector: 'app-root',
  template: `
    <abp-loader-bar></abp-loader-bar>
    <abp-dynamic-layout></abp-dynamic-layout>
  `,
})
export class AppComponent implements OnInit {
  constructor(
    private manageProfileTabs: ManageProfileTabsService
  ) {}

  ngOnInit() {
    this.manageProfileTabs.patch(eAccountManageProfileTabNames.PersonalInfo, {
      component: CustomPersonalSettingsComponent,
    });
  }
}

You can replace a tab in the my profile page by using the ManageProfileTabsService.

I hope this helps you.

beuko created 4 years ago

Hello.

Thanks, it works. Is there any guide on how to add aditional field to Profile.Response or how to extend Profile class and module to add new field so user can update it?

beuko created 4 years ago

I am following this guide here: https://docs.abp.io/en/abp/latest/Customizing-Application-Modules-Overriding-Services#extending-data-transfer-objects but I don't have class YourProjectNameDtoExtensions in my solution.

I created application with abp suite version 4.3.0.

maliming created 4 years ago

Support Team Fullstack Developer

You can create a MyProjectNameDtoExtensions file in your Application.Contracts layer.

https://github.com/abpframework/abp/blob/dev/templates/app/aspnet-core/src/MyCompanyName.MyProjectName.Application.Contracts/MyProjectNameDtoExtensions.cs

I will add this file to next version of app pro template.

beuko created 4 years ago

Hi, thanks for answer.

I created file but I can not extend ProfileDto and UpdateProfileDto. What am I missing? I have boolean field EmailNotifications, which I added to AppUser class and to MyProjectExtensionConfigurator. It shows on Administrations/Identity Managament/Users and also it works when I edit it there. Now I want to add this field to Personal info, so user can check/uncheck it himself. I followed your guide but can not add my custom property to ProfileDto. I found this line of code which populated ExtraProperties of ProfileDto but not also UpdateProfileDto. What am I doing wrong?

Thanks for your answers!

maliming created 4 years ago

Support Team Fullstack Developer

hi beuko

Can you share your full code about extending-data-transfer-objects?

beuko created 4 years ago

AppUser.cs

//added this line
public bool EmailNotifications { get; protected set; }

Application.Contracts/SKAPDtoExtensions.cs

public static class SKAPDtoExtensions
    {
        private static readonly OneTimeRunner OneTimeRunner = new OneTimeRunner();

        public static void Configure()
        {
            OneTimeRunner.Run(() =>
            {
                /* You can add extension properties to DTOs
                 * defined in the depended modules.
                 *
                 * Example:
                 *
                 * ObjectExtensionManager.Instance
                 *   .AddOrUpdateProperty("Title");
                 *
                 * See the documentation for more:
                 * https://docs.abp.io/en/abp/latest/Object-Extensions
                 */

                ObjectExtensionManager.Instance
                .AddOrUpdateProperty(
                    new[]
                    {
                        typeof(ProfileDto),
                        typeof(UpdateProfileDto)
                    },
                    "EmailNotifications"
                );

            });
        }
    }

Domain.Shared/SKAPModuleExtensionConfigurator.cs

public static class SKAPModuleExtensionConfigurator
    {
        private static readonly OneTimeRunner OneTimeRunner = new OneTimeRunner();

        public static void Configure()
        {
            OneTimeRunner.Run(() =>
            {
                ConfigureExistingProperties();
                ConfigureExtraProperties();
            });
        }

        private static void ConfigureExtraProperties()
        {
            /* You can configure extra properties for the
             * entities defined in the modules used by your application.
             *
             * This class can be used to define these extra properties
             * with a high level, easy to use API.
             *
             * Example: Add a new property to the user entity of the identity module

               ObjectExtensionManager.Instance.Modules()
                  .ConfigureIdentity(identity =>
                  {
                      identity.ConfigureUser(user =>
                      {
                          user.AddOrUpdateProperty( //property type: string
                              "SocialSecurityNumber", //property name
                              property =>
                              {
                                  //validation rules
                                  property.Attributes.Add(new RequiredAttribute());
                                  property.Attributes.Add(new StringLengthAttribute(64) {MinimumLength = 4});

                                  //...other configurations for this property
                              }
                          );
                      });
                  });

             * See the documentation for more:
             * https://docs.abp.io/en/abp/latest/Module-Entity-Extensions
             */


            ObjectExtensionManager.Instance.Modules()
            .ConfigureIdentity(identity =>
            {
                identity.ConfigureUser(user =>
                {
                    user.AddOrUpdateProperty(
                        "EmailNotifications",
                        options =>
                        {
                            options.DefaultValue = false;
                        }
                    );
                });
            });

        }
    }
