Activities of "jaylin"

All Question Answer
Newest Oldest
Stripe webhook failed - The given key 'Stripe-Signature' was not present in the dictionary #8187
Answer

Welcome back maliming, thanks for your reply.

I have resolved this issue referring to the others reply, similar to yours but ExposeService.

[ExposeServices(typeof(StripePaymentGateway))]
public class CustomStripeGateway : StripePaymentGateway
{
    public CustomStripeGateway(
        IPaymentRequestRepository paymentRequestRepository,
        IPurchaseParameterListGenerator purchaseParameterListGenerator,
        IPlanRepository planRepository,
        IOptions<StripeOptions> stripeOptions,
        ILogger<StripePaymentGateway> logger,
        IDistributedEventBus eventBus,
        IObjectMapper objectMapper
    )
        : base(
            paymentRequestRepository,
            purchaseParameterListGenerator,
            planRepository,
            stripeOptions,
            logger,
            eventBus,
            objectMapper
        )
    { }

    public override Task HandleWebhookAsync(string payload, Dictionary<string, string> headers)
    {
        if (!headers.ContainsKey("Stripe-Signature") && headers.ContainsKey("stripe-signature"))
        {
            headers["Stripe-Signature"] = headers["stripe-signature"];
            headers.Remove("stripe-signature");

            // Log the information
            Logger.LogInformation("Stripe-Signature header was missing, but stripe-signature was present. Converted stripe-signature to Stripe-Signature.");
        }

        // Volo Stripe Payment expects Stripe-Signature in the headers
        return base.HandleWebhookAsync(payload, headers);
    }
}
Stripe webhook failed - The given key 'Stripe-Signature' was not present in the dictionary #8187
Answer

Is the header key case sensitive? I captured the header in the request, its lower case.

"stripe-signature": [ "t=1730242133,v1=decaaca94f84b9e6c0523c2f283945f52a8a2e6ce0ab654bade8aa51dc2a98a5,v0=08b2da9f09b998a63e483b36ee2cf7325769eeb650ab665ed42f3e14f4cfc69a" ],

Stripe webhook failed - The given key 'Stripe-Signature' was not present in the dictionary #8187
Answer

I have Application Gateway (WAF_v2) in front of the API (webhook), even I disabled the Web Application Firewall, the issue still happened.

Problem Id System.Collections.Generic.KeyNotFoundException at Volo.Payment.Stripe.StripePaymentGateway+<HandleWebhookAsync>d__25.MoveNext Assembly Volo.Payment.Stripe.Domain, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null ActionId 46ab5810-8ae3-4668-88ec-1dc6eb213d2b ConnectionId 0HN7NVU4BKI1E MessageTemplate The given key 'Stripe-Signature' was not present in the dictionary. RequestId 0HN7NVU4BKI1E:00000006 SourceContext Volo.Abp.AspNetCore.Mvc.ExceptionHandling.AbpExceptionFilter RequestPath /api/payment/stripe/webhook ActionName Volo.Payment.Requests.PaymentRequestController.HandleWebhookAsync (Volo.Payment.HttpApi)

It's similar to https://abp.io/support/questions/4386/Error-from-ABP-commercial-payments-module-stripe-webhook-callback-handling-bug#answer-df4c481c-cbb9-299f-b150-3a08fa8e68da, but it has been resolved 2 years ago, I am wondering how comes the key was missing in the header.

I have double checked the secrets, they are correct.

Stripe webhook failed - The given key 'Stripe-Signature' was not present in the dictionary #8187
Question
  • ABP Framework version: v8.2.2
  • UI Type: Angular
  • Database System: EF Core SQL Server
  • Tiered (for MVC) or Auth Server Separated (for Angular): yes
  • Exception message and full stack trace:
System.Collections.Generic.KeyNotFoundException:
   at System.ThrowHelper.ThrowKeyNotFoundException (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Collections.Generic.Dictionary`2.get_Item (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Payment.Stripe.StripePaymentGateway+&lt;HandleWebhookAsync&gt;d__25.MoveNext (Volo.Payment.Stripe.Domain, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Payment.Requests.PaymentRequestAppService+&lt;HandleWebhookAsync&gt;d__14.MoveNext (Volo.Payment.Application, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Castle.DynamicProxy.AsyncInterceptorBase+<ProceedAsynchronous>d__14`1.MoveNext (Castle.Core.AsyncInterceptor, Version=2.1.0.0, Culture=neutral, PublicKeyToken=e33b67d3bb5581e4)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue`1+&lt;ProceedAsync&gt;d__7.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.GlobalFeatures.GlobalFeatureInterceptor+&lt;InterceptAsync&gt;d__0.MoveNext (Volo.Abp.GlobalFeatures, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter`1+<InterceptAsync>d__3`1.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Castle.DynamicProxy.AsyncInterceptorBase+<ProceedAsynchronous>d__14`1.MoveNext (Castle.Core.AsyncInterceptor, Version=2.1.0.0, Culture=neutral, PublicKeyToken=e33b67d3bb5581e4)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue`1+&lt;ProceedAsync&gt;d__7.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Auditing.AuditingInterceptor+&lt;ProceedByLoggingAsync&gt;d__4.MoveNext (Volo.Abp.Auditing, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Auditing.AuditingInterceptor+&lt;InterceptAsync&gt;d__2.MoveNext (Volo.Abp.Auditing, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter`1+<InterceptAsync>d__3`1.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Castle.DynamicProxy.AsyncInterceptorBase+<ProceedAsynchronous>d__14`1.MoveNext (Castle.Core.AsyncInterceptor, Version=2.1.0.0, Culture=neutral, PublicKeyToken=e33b67d3bb5581e4)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue`1+&lt;ProceedAsync&gt;d__7.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Validation.ValidationInterceptor+&lt;InterceptAsync&gt;d__2.MoveNext (Volo.Abp.Validation, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter`1+<InterceptAsync>d__3`1.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Castle.DynamicProxy.AsyncInterceptorBase+<ProceedAsynchronous>d__14`1.MoveNext (Castle.Core.AsyncInterceptor, Version=2.1.0.0, Culture=neutral, PublicKeyToken=e33b67d3bb5581e4)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue`1+&lt;ProceedAsync&gt;d__7.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Uow.UnitOfWorkInterceptor+&lt;InterceptAsync&gt;d__2.MoveNext (Volo.Abp.Uow, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter`1+<InterceptAsync>d__3`1.MoveNext (Volo.Abp.Castle.Core, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.ConfiguredTaskAwaitable`1+ConfiguredTaskAwaiter.GetResult (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Volo.Payment.Requests.PaymentRequestController+<HandleWebhookAsync>d__7.MoveNext (Volo.Payment.HttpApi, Version=8.2.2.0, Culture=neutral, PublicKeyToken=null)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at lambda_method3157 (Anonymously Hosted DynamicMethods Assembly, Version=0.0.0.0, Culture=neutral, PublicKeyToken=null)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ActionMethodExecutor+AwaitableObjectResultExecutor+<Execute>d__0.MoveNext (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Threading.Tasks.ValueTask`1.get_Result (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ControllerActionInvoker+&lt;&lt;InvokeActionMethodAsync&gt;g__Awaited|12_0>d.MoveNext (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ControllerActionInvoker+&lt;&lt;InvokeNextActionFilterAsync&gt;g__Awaited|10_0>d.MoveNext (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ControllerActionInvoker.Rethrow (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ControllerActionInvoker.Next (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ControllerActionInvoker.InvokeInnerFilterAsync (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
   at System.Runtime.ExceptionServices.ExceptionDispatchInfo.Throw (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at System.Runtime.CompilerServices.TaskAwaiter.HandleNonSuccessAndDebuggerNotification (System.Private.CoreLib, Version=8.0.0.0, Culture=neutral, PublicKeyToken=7cec85d7bea7798e)
   at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker+&lt;&lt;InvokeNextExceptionFilterAsync&gt;g__Awaited|26_0>d.MoveNext (Microsoft.AspNetCore.Mvc.Core, Version=8.0.0.0, Culture=neutral, PublicKeyToken=adb9793829ddae60)
  • Steps to reproduce the issue: It's working fine locally, but after deploying to Azure (Azure Container Apps), the Stripe webhook could not be triggered. I have those credentials in appSetting.json
"Payment": {
    "Stripe": {
      "PublishableKey": "pk_test_xxxx",
      "SecretKey": "sk_test_xxx",
      "WebhookSecret": "whsec_xxx"
    }
  },
Question: recurring payment for customers instead of tenants #8025
Answer

Thanks, so I have to create a new table to manage the User - Plan relation, once recurring payment comes, I need to extend the subscription expiry to next month (if recurring monthly)?

I didn't find any invoice ready "Distributed Events", how can I implement such event?

Question: recurring payment for customers instead of tenants #8025
Answer

It's nearly a week now, nobody wants to reply my question?

Question: recurring payment for customers instead of tenants #8025
Question

ABP Framework version: v8.2.2

UI Type: Angular

Database System: EF Core (SQL Server)

Tiered (for MVC) or Auth Server Separated (for Angular): yes

Exception message and full stack trace:

Steps to reproduce the issue:

My last question (https://abp.io/support/questions/7847/Stripe-Payment--Subscription-Questions) was regarding recurring payment against tenant, I managed to add EditionId and TenantId into the ExtraPropertyDictionary to link to the built-in Stripe Webhook to trigger Tenant-Edition recurring subscription.

public virtual async Task OnPost(Guid planId, Guid editionId)
{
// PaymentRequestProductDto can't edit ExtraProperties
var paymentRequest = await PaymentRequestAppService.CreateAsync(
new CustomPaymentRequestCreateDto(new ExtraPropertyDictionary() {
{ "EditionId", editionId },
{ "TenantId", CurrentTenant.Id }
})
{
Products =
{
new PaymentRequestProductCreateDto
{
PaymentType = PaymentType.Subscription,
Name = "Standard",
Code = $"{CurrentTenant.Id}\_{planId}",
Count = 1,
PlanId = planId
}
}
});

 return LocalRedirectPreserveMethod("/Payment/GatewaySelection?paymentRequestId=" + paymentRequest.Id);

}

Question: I am building a B2C platform that all users belongs to the same pre-defined tenant, how to handle the recurring subscriptions for each individual users? Do I need to include the UserId to the extra property and extend the built-in Stripe webhook? Then store the subscription expiry date for each individual user?

Any suggestions or working examples will be appreciated!

Stripe Payment / Subscription Questions #7847
Answer

I have made the Angular working. NOTE: The "subscribe" page is implemented in AuthServer (MVC Razor) because payment gateway (Stripe) prepayment is ABP's out-of-box feature, I don't want to reinvent the wheels, I did some reverse engineering though.

Similar to MVC, after installing Payment module, it added Volo.Payment.XXX and Volo.Payment.Admin.XXX nuget packages to these XXX projects and [DependsOn] in XXXModule.cs:

  1. Application
  2. Application.Contracts
  3. HttpApi
  4. HttpApi.Client

Volo.Payment.XXX and Volo.Payment.Stripe.XXX to these XXX projects and [DependsOn] in XXXModule.cs

  1. Domain
  2. Domain.Shared

As described in the document, @volo/abp.ng.payment package is needed to manage payment in Angular Admin UI.

  1. Include payment route in app-routing.module.ts
  2. Include PaymentAdminConfigModule in app.module.ts.

Volo.Payment.EntityFrameworkCore to EntityFrameworkCore project and some file changes:

  1. builder.ConfigurePayment() in DbContext.cs
  2. [DependsOn] in EntityFrameworkCoreModule
  3. EF Code First Migrations

Manual steps:

  1. Added IsPaymentSupported in XXXModule.cs to HttpApi.Host project Configure<AbpSaasPaymentOptions>(options => { options.IsPaymentSupported = true; });

  2. Added Payment Stripe in appsettings.json to HttpApi.Host project "Payment": { "Stripe": { "PublishableKey": "pk_xxxx", "SecretKey": "sk_xxx" , "WebhookSecret": "whsec_xxx", "PaymentMethodTypes": [] // card has already been added } }

  3. Added PaymentWebOptions to PreConfigureServices in XXXAuthServerModule to AuthServer project. public override void PreConfigureServices(ServiceConfigurationContext context) { ...... var configuration = context.Services.GetConfiguration(); Configure<PaymentWebOptions>(options => { options.RootUrl = configuration["App:SelfUrl"]; options.CallbackUrl = configuration["App:SelfUrl"] + "/PaymentSucceed"; }); }

  4. Added Volo.Payment.Stripe.Web and Volo.Payment.Web nuget packages to AuthServer project - to route to out-of-box prepayment. It added AbpPaymentStripeWebModule and AbpPaymentWebModule [DependsOn] in XXXAuthServerModule.

  5. Added HttpApi.Client.csproj and HttpApi.csproj projects to AuthServer project - to inject IPaymentRequestAppService in Subscribe page.

  6. Added Subscribe.cshtml to AuthServer project to allow Tenant subscribe to an Edition. However, Tenant Admin doesn't have permission to call create subscription API as per the above thread by ismcagdas.
    I did bypass "await SubscriptionAppService.CreateSubscriptionAsync(editionId, currentTenantId)" by calling PaymentRequestAppService.

    public class SubscribeModel : PageModel { private IPaymentRequestAppService PaymentRequestAppService { get; } private ICurrentTenant CurrentTenant { get; }

     public SubscribeModel(
     IPaymentRequestAppService paymentRequestAppService,
     ICurrentTenant currentTenant)
 {
     PaymentRequestAppService = paymentRequestAppService;
     CurrentTenant = currentTenant;
 }

 public virtual async Task&lt;IActionResult&gt; OnPost(Guid planId, Guid editionId)
 {
     // PaymentRequestProductDto can't edit ExtraProperties
     var paymentRequest = await PaymentRequestAppService.CreateAsync(
         new CustomPaymentRequestCreateDto(new ExtraPropertyDictionary() {
             { "EditionId", editionId },
             { "TenantId", CurrentTenant.Id }
         })
         {
             Products =
             {
                 new PaymentRequestProductCreateDto
                 {
                     PaymentType = PaymentType.Subscription,
                     Name = "Standard",
                     Code = $"{CurrentTenant.Id}_{planId}",
                     Count = 1,
                     PlanId = planId
                 }
             }
         });

     return LocalRedirectPreserveMethod("/Payment/GatewaySelection?paymentRequestId=" + paymentRequest.Id);
 }

    }

    public class CustomPaymentRequestCreateDto : PaymentRequestCreateDto { public CustomPaymentRequestCreateDto(ExtraPropertyDictionary extraProperties) { ExtraProperties = extraProperties; } }

Because PayPaymentRequests.ExtraProperties (e.g. TenantId) will be used by Stripe Webhook to update SaasTenants.EditionEndDateUtc.

Hope this thread is useful to someone in the future.

Stripe Payment / Subscription Questions #7847
Answer

Thanks ismcagdas, really appreciated!!!

// 1. Run as Tenant Admin - still not working failed at CreateSubscriptionAsync (403 Fibidden) var currentTenantId = CurrentTenant.GetId(); var currentPaymentRequest = await SubscriptionAppService.CreateSubscriptionAsync(editionId, currentTenantId);

// 2. Run as Host Admin - it works, but not ideal, Tenant Admin should pay the subscription var tenantId = new Guid("9374a261-f7c5-4c4c-ba88-3a14e2feb5d1"); var paymentRequest = await SubscriptionAppService.CreateSubscriptionAsync(editionId, tenantId); // 3. Run as Tenant Admin - it works var planId = new Guid("158c0405-7d7b-782b-6134-3a14e2d52556"); var paymentRequest = await PaymentRequestAppService.CreateAsync(new PaymentRequestCreateDto() { ...... }); return LocalRedirectPreserveMethod("/Payment/GatewaySelection?paymentRequestId=" + paymentRequest.Id);

Note for future, in case it can help someone who might face the same problem.

After install Payment module, it added Volo.Payment.XXX and Volo.Payment.Admin.XXX nuget packages to these projects and [DependsOn] in XXXModule.cs:

  1. Application
  2. Application.Contracts
  3. HttpApi
  4. HttpApi.Client

Volo.Payment.XXX and Volo.Payment.Stripe.XXX to these projects and [DependsOn] in XXXModule.cs

  1. Domain
  2. Domain.Shared

Volo.Payment.XXX, Volo.Payment.Admin.XXX and Volo.Payment.Stripe.XXX to the project and [DependsOn] in XXXModule.cs

  1. Web (MVC)

Volo.Payment.EntityFrameworkCore to EntityFrameworkCore project and some file changes:

  1. builder.ConfigurePayment() in DbContext.cs
  2. [DependsOn] in EntityFrameworkCoreModule
  3. EF Code First Migrations

Manual steps:

  1. Added IsPaymentSupported in XXXModule.cs to HttpApi.Host project Configure<AbpSaasPaymentOptions>(options => { options.IsPaymentSupported = true; });

  2. Added Payment Stripe in appsettings.json to HttpApi.Host project "Payment": { "Stripe": { "PublishableKey": "pk_xxxx", "SecretKey": "sk_xxx" , "WebhookSecret": "whsec_xxx", "PaymentMethodTypes": [] // card has already been added } }

  3. Added PaymentWebOptions to PreConfigureServices in XXXWebModule to Web project public override void PreConfigureServices(ServiceConfigurationContext context) { ......

     **var configuration = context.Services.GetConfiguration();
 Configure&lt;PaymentWebOptions&gt;(options =>
 {
     options.RootUrl = configuration["App:SelfUrl"];
     options.CallbackUrl = configuration["App:SelfUrl"] + "/PaymentSucceed";
 });**

    }

  4. Added Subscribe.cshtml to Web project to allow Tenant subscribe to an Edition.

I will work on Angular version, and post the configuration once done.

Stripe Payment / Subscription Questions #7847
Answer

PaymentRequestService failed at /api/payment/stripe/start the same as above thread.

[13:28:06 INF] Sending HTTP request POST https://localhost:44330/api/payment/stripe/start?api-version=1.0 [13:28:07 INF] Received HTTP response headers after 968.9722ms - 500 [13:28:07 INF] End processing HTTP request after 969.1742ms - 500 [13:28:07 ERR] ---------- RemoteServiceErrorInfo ---------- { "code": null, "message": "An internal error occurred during your request!", "details": null, "data": {}, "validationErrors": null }

[13:28:07 ERR] An internal error occurred during your request! Volo.Abp.Http.Client.AbpRemoteCallException: An internal error occurred during your request! at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.ThrowExceptionForResponseAsync(HttpResponseMessage response) at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.RequestAsync(ClientProxyRequestContext requestContext) at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.RequestAsync[T](ClientProxyRequestContext requestContext) at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.RequestAsync[T](String methodName, ClientProxyRequestTypeValue arguments) at Volo.Payment.Requests.ClientProxies.PaymentRequestClientProxy.StartAsync(String paymentMethod, PaymentRequestStartDto input) at Volo.Payment.Stripe.Pages.Payment.Stripe.PrePaymentModel.OnPostAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.ExecutorFactory.NonGenericTaskHandlerMethod.Execute(Object receiver, Object[] arguments) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeHandlerMethodAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeNextPageFilterAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.Rethrow(PageHandlerExecutedContext context) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeInnerFilterAsync() at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeNextExceptionFilterAsync>g__Awaited|26_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) [13:28:07 ERR] Code: [13:28:07 ERR] Details: [13:28:07 INF] Executed page /Payment/Stripe/PrePayment in 1007.7672ms [13:28:07 INF] Executed endpoint '/Payment/Stripe/PrePayment' [13:28:07 ERR] An unhandled exception has occurred while executing the request. Volo.Abp.Http.Client.AbpRemoteCallException: An internal error occurred during your request! at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.ThrowExceptionForResponseAsync(HttpResponseMessage response) at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.RequestAsync(ClientProxyRequestContext requestContext) at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.RequestAsync[T](ClientProxyRequestContext requestContext) at Volo.Abp.Http.Client.ClientProxying.ClientProxyBase1.RequestAsync[T](String methodName, ClientProxyRequestTypeValue arguments) at Volo.Payment.Requests.ClientProxies.PaymentRequestClientProxy.StartAsync(String paymentMethod, PaymentRequestStartDto input) at Volo.Payment.Stripe.Pages.Payment.Stripe.PrePaymentModel.OnPostAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.ExecutorFactory.NonGenericTaskHandlerMethod.Execute(Object receiver, Object[] arguments) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeHandlerMethodAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeNextPageFilterAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.Rethrow(PageHandlerExecutedContext context) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeInnerFilterAsync() at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeNextExceptionFilterAsync>g__Awaited|26_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Rethrow(ExceptionContextSealed context) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeNextResourceFilter>g__Awaited|25_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Rethrow(ResourceExecutedContextSealed context) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeFilterPipelineAsync>g__Awaited|20_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeAsync>g__Logged|17_1(ResourceInvoker invoker) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeAsync>g__Logged|17_1(ResourceInvoker invoker) at Microsoft.AspNetCore.Routing.EndpointMiddleware.<Invoke>g__AwaitRequestTask|7_0(Endpoint endpoint, Task requestTask, ILogger logger) at Volo.Abp.AspNetCore.Serilog.AbpSerilogMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Swashbuckle.AspNetCore.SwaggerUI.SwaggerUIMiddleware.Invoke(HttpContext httpContext) at Swashbuckle.AspNetCore.Swagger.SwaggerMiddleware.Invoke(HttpContext httpContext, ISwaggerProvider swaggerProvider) at Microsoft.AspNetCore.Authorization.AuthorizationMiddleware.Invoke(HttpContext context) at Volo.Abp.AspNetCore.Security.Claims.AbpDynamicClaimsMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Volo.Abp.AspNetCore.MultiTenancy.MultiTenancyMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Authentication.AuthenticationMiddleware.Invoke(HttpContext context) at Volo.Abp.AspNetCore.Security.AbpSecurityHeadersMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Volo.Abp.Studio.Client.AspNetCore.AbpStudioMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Volo.Abp.Studio.Client.AspNetCore.AbpStudioMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Volo.Abp.Studio.Client.AspNetCore.AbpStudioMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Localization.RequestLocalizationMiddleware.Invoke(HttpContext context) at Microsoft.AspNetCore.RequestLocalization.AbpRequestLocalizationMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Diagnostics.DeveloperExceptionPageMiddlewareImpl.Invoke(HttpContext context) [13:28:07 INF] Request finished HTTP/2 POST https://localhost:44380/Payment/Stripe/PrePayment?paymentRequestId=a23c0f0e-62ca-9eab-78fc-3a14f14c5b60 - 500 null text/html; charset=utf-8 1097.2184ms

    public virtual async Task&lt;IActionResult&gt; OnPost()
    {
        var planId = new Guid("158c0405-7d7b-782b-6134-3a14e2d52556");
        var paymentRequest = await PaymentRequestAppService.CreateAsync(
            new PaymentRequestCreateDto()
            {
                Products =
                {
                    new PaymentRequestProductCreateDto
                    {
                        PaymentType = PaymentType.Subscription,
                        Name = "Enterprise Plan",
                        Code = "EP",
                        Count = 1,
                        // Place your created PlanId below.
                        PlanId = planId
                    }
                }
            });
            return LocalRedirectPreserveMethod("/Payment/GatewaySelection?paymentRequestId=" + paymentRequest.Id);
    }
Showing 1 to 10 of 17 entries
Made with ❤️ on ABP v9.1.0-preview. Updated on November 20, 2024, 13:06
