I also don't like this change. We have angular in a separate repo. Is there a way to make the ABP Solution work with the "old" folder structure?
You need to look in the backend logs. 500 errors are logged there
It looks like the "ProviderKey" column in the "AbpUserLogins" table is now encrypted, or in a different format. After clearing the table, things started to work again...
Not sure if that's documented somewhere
ABP Framework version: v8.0.4
UI Type: Angular
Database System: EF Core (SQL Server)
Tiered (for MVC) or Auth Server Separated (for Angular): yes
Exception message and full stack trace:
EXCEPTION: System.InvalidOperationException: The instance of entity type 'IdentityUserLogin' cannot be tracked because another instance with the same key value for {'UserId', 'LoginProvider'} is already being tracked. When attaching existing entities, ensure that only one entity instance with a given key value is attached. Consider using 'DbContextOptionsBuilder.EnableSensitiveDataLogging' to see the conflicting key values. at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.IdentityMap1.ThrowIdentityConflict(InternalEntityEntry entry)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.IdentityMap1.Add(TKey key, InternalEntityEntry entry, Boolean updateDuplicate) at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.IdentityMap1.Add(TKey key, InternalEntityEntry entry)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.NullableKeyIdentityMap1.Add(InternalEntityEntry entry) at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.StateManager.StartTracking(InternalEntityEntry entry) at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.InternalEntityEntry.SetEntityState(EntityState oldState, EntityState newState, Boolean acceptChanges, Boolean modifyProperties) at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.InternalEntityEntry.SetEntityState(EntityState entityState, Boolean acceptChanges, Boolean modifyProperties, Nullable1 forceStateWhenUnknownKey, Nullable1 fallbackState) at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.EntityGraphAttacher.PaintAction(EntityEntryGraphNode1 node)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.EntityEntryGraphIterator.TraverseGraph[TState](EntityEntryGraphNode1 node, Func2 handleNode)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.EntityGraphAttacher.AttachGraph(InternalEntityEntry rootEntry, EntityState targetState, EntityState storeGeneratedWithKeySetTargetState, Boolean forceStateWhenUnknownKey)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.NavigationFixer.NavigationCollectionChanged(InternalEntityEntry entry, INavigationBase navigationBase, IEnumerable1 added, IEnumerable1 removed)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.InternalEntityEntryNotifier.NavigationCollectionChanged(InternalEntityEntry entry, INavigationBase navigationBase, IEnumerable1 added, IEnumerable1 removed)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.ChangeDetector.DetectNavigationChange(InternalEntityEntry entry, INavigationBase navigationBase)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.ChangeDetector.LocalDetectChanges(InternalEntityEntry entry)
at Microsoft.EntityFrameworkCore.ChangeTracking.Internal.ChangeDetector.DetectChanges(IStateManager stateManager)
at Microsoft.EntityFrameworkCore.ChangeTracking.ChangeTracker.DetectChanges()
at Microsoft.EntityFrameworkCore.Internal.InternalDbSet1.get_Local() at Volo.Abp.Domain.Repositories.EntityFrameworkCore.EfCoreRepository2.UpdateAsync(TEntity entity, Boolean autoSave, CancellationToken cancellationToken)
at Castle.DynamicProxy.AsyncInterceptorBase.ProceedAsynchronous[TResult](IInvocation invocation, IInvocationProceedInfo proceedInfo)
at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue1.ProceedAsync() at Volo.Abp.Uow.UnitOfWorkInterceptor.InterceptAsync(IAbpMethodInvocation invocation) at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter1.InterceptAsync[TResult](IInvocation invocation, IInvocationProceedInfo proceedInfo, Func3 proceed) at Volo.Abp.Identity.IdentityUserStore.UpdateAsync(IdentityUser user, CancellationToken cancellationToken) at Microsoft.AspNetCore.Identity.UserManager1.UpdateUserAsync(TUser user)
at Castle.DynamicProxy.AsyncInterceptorBase.ProceedAsynchronous[TResult](IInvocation invocation, IInvocationProceedInfo proceedInfo)
at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue1.ProceedAsync() at Volo.Abp.Uow.UnitOfWorkInterceptor.InterceptAsync(IAbpMethodInvocation invocation) at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter1.InterceptAsync[TResult](IInvocation invocation, IInvocationProceedInfo proceedInfo, Func3 proceed) at Microsoft.AspNetCore.Identity.UserManager1.AddLoginAsync(TUser user, UserLoginInfo login)
at Castle.DynamicProxy.AsyncInterceptorBase.ProceedAsynchronous[TResult](IInvocation invocation, IInvocationProceedInfo proceedInfo)
at Volo.Abp.Castle.DynamicProxy.CastleAbpMethodInvocationAdapterWithReturnValue1.ProceedAsync() at Volo.Abp.Uow.UnitOfWorkInterceptor.InterceptAsync(IAbpMethodInvocation invocation) at Volo.Abp.Castle.DynamicProxy.CastleAsyncAbpInterceptorAdapter1.InterceptAsync[TResult](IInvocation invocation, IInvocationProceedInfo proceedInfo, Func3 proceed) at Volo.Abp.Account.Public.Web.Pages.Account.LoginModel.OnGetExternalLoginCallbackAsync(String remoteError) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.ExecutorFactory.GenericTaskHandlerMethod.Convert[T](Object taskAsObject) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.ExecutorFactory.GenericTaskHandlerMethod.Execute(Object receiver, Object[] arguments) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeHandlerMethodAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeNextPageFilterAsync() at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.Rethrow(PageHandlerExecutedContext context) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.RazorPages.Infrastructure.PageActionInvoker.InvokeInnerFilterAsync() at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeNextExceptionFilterAsync>g__Awaited|26_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Rethrow(ExceptionContextSealed context) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeNextResourceFilter>g__Awaited|25_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Rethrow(ResourceExecutedContextSealed context) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.Next(State& next, Scope& scope, Object& state, Boolean& isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeFilterPipelineAsync>g__Awaited|20_0(ResourceInvoker invoker, Task lastTask, State next, Scope scope, Object state, Boolean isCompleted) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeAsync>g__Logged|17_1(ResourceInvoker invoker) at Microsoft.AspNetCore.Mvc.Infrastructure.ResourceInvoker.<InvokeAsync>g__Logged|17_1(ResourceInvoker invoker) at company.Product.Common.AspNetCore.logMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) in /src/src/company.Product.Common.AspNetCore/logMiddleware.cs:line 42 at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Volo.Abp.AspNetCore.Auditing.AbpAuditingMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Authorization.AuthorizationMiddleware.Invoke(HttpContext context) at Volo.Abp.AspNetCore.Uow.AbpUnitOfWorkMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Volo.Abp.AspNetCore.ExceptionHandling.AbpExceptionHandlingMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Volo.Abp.AspNetCore.ExceptionHandling.AbpExceptionHandlingMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Volo.Abp.AspNetCore.MultiTenancy.MultiTenancyMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Builder.ApplicationBuilderAbpOpenIddictMiddlewareExtension.<>c__DisplayClass0_0.<<UseAbpOpenIddictValidation>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Authentication.AuthenticationMiddleware.Invoke(HttpContext context) at Volo.Abp.AspNetCore.Security.AbpSecurityHeadersMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Volo.Abp.AspNetCore.Tracing.AbpCorrelationIdMiddleware.InvokeAsync(HttpContext context, RequestDelegate next) at Microsoft.AspNetCore.Builder.UseMiddlewareExtensions.InterfaceMiddlewareBinder.<>c__DisplayClass2_0.<<CreateMiddleware>b__0>d.MoveNext() --- End of stack trace from previous location --- at Microsoft.AspNetCore.Diagnostics.ExceptionHandlerMiddlewareImpl.<Invoke>g__Awaited|10_0(ExceptionHandlerMiddlewareImpl middleware, HttpContext context, Task task)
Steps to reproduce the issue: After updating to ABP 8.0.4, we have a problem logging in with External Authentication, we get a 500 error. Any ideas?
Going further with this, I have tried it using just ASP.NET Core, and the type seems to be represented just fine in ApiExplorer with this. I'll send you the project
Actually, going further it seems the issue is not class vs struct, but that the type is used in a route path, e.g:
[HttpPost("/class/{testClass}")]
public ActionResult FromTestClass(TestClass testClass)
{
return NoContent();
}
This produces 2 parameters, one for the route {testClass} with no Type and one for the function itself with the correct type info.
So this seems to be the culprit here
Going further with this, I have tried it using just ASP.NET Core, and the type seems to be represented just fine in ApiExplorer with this. I'll send you the project
It must be something with ASP.NET Core then (or the way ABP uses the information), you can get rid of StronglyTypedId package / code and just use this for AgentId:
namespace Repro.ProxyGeneration.Models.Test
{
public struct AgentId
{
public int Value { get; }
public AgentId(int value)
{
Value = value;
}
}
}
This leads to the same issue. The workaround seems to work and my proxies do get generated again, thank you
From what I can see is that it fails here in @abp\ng.schematics\utils\common.js
Object.values(controller.actions || {}).forEach(a => {
a.returnValue.type = sanitizeTypeName(a.returnValue.type);
a.returnValue.typeSimple = sanitizeTypeName(a.returnValue.typeSimple);
a.parametersOnMethod?.forEach(p => {
p.type = sanitizeTypeName(p.type);
p.typeAsString = sanitizeTypeName(p.typeAsString);
p.typeSimple = sanitizeTypeName(p.typeSimple);
});
a.parameters?.forEach(p => {
p.type = sanitizeTypeName(p.type);
p.typeSimple = sanitizeTypeName(p.typeSimple);
});
});
Specifically here:
a.parameters?.forEach(p => {
p.type = sanitizeTypeName(p.type); <--------
p.typeSimple = sanitizeTypeName(p.typeSimple);
});
Looking into my api-definition, I get for instance this generated parameter on a method:
"paramters": [
{
"nameOnMethod": "agentApiKeyId",
"name": "agentApiKeyId",
"jsonName": null,
"type": null,
"typeSimple": null,
"isOptional": false,
"defaultValue": null,
"constraintTypes": [],
"bindingSourceId": "Path",
"descriptorName": ""
}
]
notice how the type is null.
This particular method is in a Controller (however we observe the same from ApplicationServices as well):
[HttpPost]
[Route("api-keys/{agentApiKeyId}")]
public async Task<ActionResult> SetAgentApiKeyStatusAsync(AgentApiKeyId agentApiKeyId, bool isEnabled)
{
await _agentAppService.SetApiKeyStatusAsync(agentApiKeyId, isEnabled);
return NoContent();
}
Now, AgentApiKeyId itself is a value object struct (generated by the StronglyTypedId project) :
//------------------------------------------------------------------------------
// <auto-generated>
// This code was generated by the StronglyTypedId source generator
//
// Changes to this file may cause incorrect behavior and will be lost if
// the code is regenerated.
// </auto-generated>
//------------------------------------------------------------------------------
#pragma warning disable 1591 // publicly visible type or member must be documented
namespace MyCompany.MyProject.Agent.ValueObjectId
{
[System.Text.Json.Serialization.JsonConverter(typeof(AgentApiKeyIdSystemTextJsonConverter))]
[System.ComponentModel.TypeConverter(typeof(AgentApiKeyIdTypeConverter))]
readonly partial struct AgentApiKeyId : System.IComparable<AgentApiKeyId>, System.IEquatable<AgentApiKeyId>
{
public int Value { get; }
public AgentApiKeyId(int value)
{
Value = value;
}
public static readonly AgentApiKeyId Empty = new AgentApiKeyId(0);
public bool Equals(AgentApiKeyId other) => this.Value.Equals(other.Value);
public override bool Equals(object obj)
{
if (ReferenceEquals(null, obj)) return false;
return obj is AgentApiKeyId other && Equals(other);
}
public override int GetHashCode() => Value.GetHashCode();
public override string ToString() => Value.ToString();
public static bool operator ==(AgentApiKeyId a, AgentApiKeyId b) => a.Equals(b);
public static bool operator !=(AgentApiKeyId a, AgentApiKeyId b) => !(a == b);
public int CompareTo(AgentApiKeyId other) => Value.CompareTo(other.Value);
public class EfCoreValueConverter : Microsoft.EntityFrameworkCore.Storage.ValueConversion.ValueConverter<AgentApiKeyId, int>
{
public EfCoreValueConverter() : this(null) { }
public EfCoreValueConverter(Microsoft.EntityFrameworkCore.Storage.ValueConversion.ConverterMappingHints mappingHints = null)
: base(
id => id.Value,
value => new AgentApiKeyId(value),
mappingHints
) { }
}
class AgentApiKeyIdTypeConverter : System.ComponentModel.TypeConverter
{
public override bool CanConvertFrom(System.ComponentModel.ITypeDescriptorContext context, System.Type sourceType)
{
return sourceType == typeof(int) || sourceType == typeof(string) || base.CanConvertFrom(context, sourceType);
}
public override object ConvertFrom(System.ComponentModel.ITypeDescriptorContext context, System.Globalization.CultureInfo culture, object value)
{
return value switch
{
int intValue => new AgentApiKeyId(intValue),
string stringValue when !string.IsNullOrEmpty(stringValue) && int.TryParse(stringValue, out var result) => new AgentApiKeyId(result),
_ => base.ConvertFrom(context, culture, value),
};
}
public override bool CanConvertTo(System.ComponentModel.ITypeDescriptorContext context, System.Type sourceType)
{
return sourceType == typeof(int) || sourceType == typeof(string) || base.CanConvertTo(context, sourceType);
}
public override object ConvertTo(System.ComponentModel.ITypeDescriptorContext context, System.Globalization.CultureInfo culture, object value, System.Type destinationType)
{
if (value is AgentApiKeyId idValue)
{
if (destinationType == typeof(int))
{
return idValue.Value;
}
if (destinationType == typeof(string))
{
return idValue.Value.ToString();
}
}
return base.ConvertTo(context, culture, value, destinationType);
}
}
class AgentApiKeyIdSystemTextJsonConverter : System.Text.Json.Serialization.JsonConverter<AgentApiKeyId>
{
public override AgentApiKeyId Read(ref System.Text.Json.Utf8JsonReader reader, System.Type typeToConvert, System.Text.Json.JsonSerializerOptions options)
{
return new AgentApiKeyId(reader.GetInt32());
}
public override void Write(System.Text.Json.Utf8JsonWriter writer, AgentApiKeyId value, System.Text.Json.JsonSerializerOptions options)
{
writer.WriteNumberValue(value.Value);
}
}
}
}
It seems like struct's are not correctly processed when generating the api-definition. Is this something that can be fixed?
I was able to get a stack trace by using this:
yarn nx g @abp/nx.generators:generate-proxy --verbose
maybe it helps?
TypeError: Cannot read properties of null (reading 'replace')
at sanitizeTypeName (W:\DEV\ProductName\abp\angular\node_modules\@abp\ng.schematics\utils\common.js:35:41)
at W:\DEV\ProductName\abp\angular\node_modules\@abp\ng.schematics\utils\common.js:58:26
at Array.forEach (<anonymous>)
at W:\DEV\ProductName\abp\angular\node_modules\@abp\ng.schematics\utils\common.js:57:27
at Array.forEach (<anonymous>)
at W:\DEV\ProductName\abp\angular\node_modules\@abp\ng.schematics\utils\common.js:49:49
at Array.forEach (<anonymous>)
at sanitizeControllerTypeNames (W:\DEV\ProductName\abp\angular\node_modules\@abp\ng.schematics\utils\common.js:37:38)
at W:\DEV\ProductName\abp\angular\node_modules\@abp\ng.schematics\commands\api\index.js:31:92
at process.processTicksAndRejections (node:internal/process/task_queues:95:5)
{
"name": "ProductName",
"version": "0.0.0",
"scripts": {
"ng": "ng",
"start": "ng serve --open",
"start:development-staging": "ng server --open --configuration development-staging",
"build": "ng build",
"build:docker-compose": "ng build --configuration docker-compose",
"build:development-staging": "ng build --configuration development-staging",
"build:prod": "ng build --configuration production",
"watch": "ng build --watch --configuration development",
"test": "ng test",
"lint": "ng lint"
},
"private": true,
"dependencies": {
"@abp/ng.components": "~7.4.2",
"@abp/ng.core": "~7.4.2",
"@abp/ng.oauth": "~7.4.2",
"@abp/ng.setting-management": "~7.4.2",
"@abp/ng.theme.shared": "~7.4.2",
"@amcharts/amcharts4": "^4.10.38",
"@angular-builders/jest": "^16.0.0",
"@angular/animations": "^16.2.12",
"@angular/common": "^16.2.12",
"@angular/compiler": "^16.2.12",
"@angular/core": "^16.2.12",
"@angular/forms": "^16.2.12",
"@angular/localize": "16.2.12",
"@angular/platform-browser": "^16.2.12",
"@angular/platform-browser-dynamic": "^16.2.12",
"@angular/router": "^16.2.12",
"@chiragrupani/karma-chromium-edge-launcher": "^2.1.1",
"@ngxs/store": "^3.7.6",
"@swimlane/ngx-charts": "^20.0.0",
"@volo/abp.commercial.ng.ui": "~7.4.2",
"@volo/abp.ng.account": "~7.4.2",
"@volo/abp.ng.audit-logging": "~7.4.2",
"@volo/abp.ng.gdpr": "~7.4.2",
"@volo/abp.ng.identity": "~7.4.2",
"@volo/abp.ng.language-management": "~7.4.2",
"@volo/abp.ng.openiddictpro": "~7.4.2",
"@volo/abp.ng.saas": "~7.4.2",
"@volo/abp.ng.text-template-management": "~7.4.2",
"@volo/abp.ng.theme.lepton": "7.4.2",
"@volo/language-management": "~7.4.2",
"@yaireo/tagify": "^4.17.0",
"bootstrap-icons": "^1.11.2",
"jest": "^29.7.0",
"karma-junit-reporter": "^2.0.1",
"ngx-bootstrap-multiselect": "^4.0.0",
"ngx-editor": "^16.0.0",
"rxjs": "7.8.1",
"tslib": "^2.1.0",
"zone.js": "~0.13.3"
},
"devDependencies": {
"@abp/ng.schematics": "~7.4.2",
"@angular-devkit/build-angular": "^16.2.10",
"@angular-eslint/builder": "16.3.1",
"@angular-eslint/eslint-plugin": "16.3.1",
"@angular-eslint/eslint-plugin-template": "16.3.1",
"@angular-eslint/schematics": "16.3.1",
"@angular-eslint/template-parser": "16.3.1",
"@angular/cli": "^16.2.10",
"@angular/compiler-cli": "^16.2.12",
"@angular/language-service": "^16.2.12",
"@types/jasmine": "~3.6.0",
"@types/node": "^18.11.0",
"@typescript-eslint/eslint-plugin": "^5.59.2",
"@typescript-eslint/parser": "^5.59.2",
"eslint": "^8.39.0",
"jasmine-core": "~4.0.0",
"karma": "~6.3.0",
"karma-chrome-launcher": "~3.1.0",
"karma-coverage": "~2.1.0",
"karma-jasmine": "~4.0.0",
"karma-jasmine-html-reporter": "^1.7.0",
"ng-packagr": "^16.2.3",
"typescript": "~5.1.6"
},
"resolutions": {
"prosemirror-view": "1.31.7"
}
}
