how to config the parameter for this ' https://localhost:44380/.well-known/openid-configuration' #10159

1 Answer(s)

•

  0

  AI-Bot created 25 days ago

  Support Team ABP Agent

  1. Solution To make the Angular app request the OpenID Connect discovery document from your real server host instead of https://localhost:44380, you must configure both the Angular environment and the backend Authority/SelfUrl consistently for your deployment host.

  Do the following:

  • Angular (environment.prod.ts)
    • Set baseUrl to the public Angular URL you are using in production.
    • Set oAuthConfig.issuer to your backend’s public HTTPS authority (with a trailing slash).
    • Keep requireHttps = true for production (recommended).
    • Example:

  import { Environment } from '@abp/ng.core';

    const baseUrl = 'http://serviceip:4200'; // or https if you have TLS on the SPA

    const oAuthConfig = {
      issuer: 'https://serverhost:44380/', // IMPORTANT: public HTTPS authority with trailing slash
      redirectUri: baseUrl,
      clientId: 'NovaLab_App',
      responseType: 'code',
      scope: 'offline_access NovaLab',
      requireHttps: true,
      impersonation: {
        tenantImpersonation: true,
        userImpersonation: true,
      },
    };

    export const environment = {
      production: true,
      application: {
        baseUrl,
        name: 'NovaLab',
      },
      oAuthConfig,
      apis: {
        default: {
          url: 'https://serverhost:44380', // same host as issuer
          rootNamespace: 'RZ.NovaLab',
        },
        AbpAccountPublic: {
          url: oAuthConfig.issuer,
          rootNamespace: 'AbpAccountPublic',
        },
      },
      remoteEnv: {
        url: '/getEnvConfig',
        mergeStrategy: 'deepmerge',
      },
    } as Environment;


  • Backend (HttpApi.Host or AuthServer)
    • Ensure App:SelfUrl equals your public HTTPS root (https://serverhost:44380).
    • Set AuthServer:Authority to the same public HTTPS URL.
    • If you’re behind a reverse proxy/loader (IIS, Nginx, Azure App Service, etc.), make sure the backend generates HTTPS endpoints inside the discovery document. Add forwarded headers and/or force scheme to https:

  // Program.cs or the module's OnApplicationInitialization:
    app.UseForwardedHeaders(new ForwardedHeadersOptions
    {
        ForwardedHeaders = ForwardedHeaders.XForwardedProto | ForwardedHeaders.XForwardedFor
    });

    // If your proxy doesn’t set X-Forwarded-Proto properly, force https as a fallback:
    app.Use(async (ctx, next) =>
    {
        ctx.Request.Scheme = "https";
        await next();
    });


  • When using OpenIddict, ensure the issuer matches your public HTTPS authority:

  PreConfigure<OpenIddictServerBuilder>(builder =>
    {
        builder.SetIssuer(new Uri(configuration["AuthServer:Authority"]!)); // https://serverhost:44380
    });


  • Common pitfalls to avoid
    • Mismatch between Angular issuer and backend Authority/SelfUrl. They must point to the same public host and scheme.
    • Missing trailing slash in issuer on Angular. Add it (…/).
    • Using http in production: Angular’s OAuth library validates that all discovery document URLs are HTTPS when requireHttps is true. Ensure your discovery document (/.well-known/openid-configuration) shows HTTPS for issuer, authorization_endpoint, token_endpoint, jwks_uri, etc. If it shows http, fix proxy headers or force https as shown above.

  After these changes, browsing http://serviceip:4200 (or https if applicable) should fetch the discovery document from https://serverhost:44380/.well-known/openid-configuration instead of https://localhost:44380, and complete the OIDC flow successfully.

  2. Sources

  • OpenIddict Angular Migration (issuer trailing slash)
    • https://abp.io/docs/latest/release-info/migration-guides/openiddict-angular
  • Related support threads on ensuring issuer/authority match and HTTPS discovery behind proxies
    • https://abp.io/support/questions/4338
    • https://abp.io/support/questions/10011

  ---
