Failed to load API definition - 500 Internal Server Error on the /api/abp/application-configuration - Fetch error OK /swagger/v1/swagger.json #10358 | Support

devchase321 created 3 days ago

Hello,

We are facing Error 500 issues with API after deploying to Azure Container App. Same application using appsettings.development.json config runs fine locally. We need your help spotting any misconfigured on our end.

Failed to load API definition - 500 Internal Server Error on the /api/abp/application-configuration - Fetch error OK /swagger/v1/swagger.json

More details - source files here: https://drive.google.com/drive/folders/1P88jaMPzPbPd9HLima4ZEj1HF-GUHu9H?usp=drive_link

ABP Studio Configuration Information:

Template: app
Created ABP Studio Version: 2.1.0
Current ABP Studio Version: 2.1.7
Tiered: Yes
Multi-Tenancy: Yes
UI Framework: blazor-server
Theme: leptonx
Theme Style: system
Theme Menu Placement: side
Database Provider: ef
Database Management System: sqlserver
Separate Tenant Schema: Yes
Mobile Framework: none
Public Website: Yes
Social Login: Yes
Include Tests: Yes
Kubernetes Configuration: Yes
Distributed Event Bus: rabbitmq
Use Local References: No
Optional Modules:
- GDPR
- FileManagement
- TextTemplateManagement
- LanguageManagement
- AuditLogging
- Chat
- OpenIddictAdmin
Selected Languages: English, French, Spanish
Default Language: English
Create Command: abp new Millennial -t app --tiered --ui-framework blazor-server --database-provider ef --database-management-system sqlserver --theme leptonx --separate-tenant-schema --skip-migration --skip-migrator --public-website --without-cms-kit --dont-run-install-libs --dont-run-bundling -chat -file-management

What we have tried: Validated OpenIddict Application values in DB and Admin console Validated values in AppSettings.json files

AI-Bot created 3 days ago

Support Team ABP Agent

Solution

In ABP applications, both:

/api/abp/application-configuration
/swagger/v1/swagger.json

are among the very first endpoints that hit all your infrastructure (DB, Redis, distributed cache, OpenIddict, etc.).
After deployment to Azure Container Apps, a 500 here almost always means environment‑specific configuration (especially Redis / cache / connection strings / certificates) is wrong.

Below is a concrete checklist that matches your scenario (tiered, Redis/RabbitMQ, containers) and what we’ve seen in similar ABP support tickets.

1. Check the real exception in the API logs

First, get the HttpApi.Host container logs and look for the first stack trace that appears when you call:

https://<your-api>/api/abp/application-configuration
or
https://<your-api>/swagger/v1/swagger.json

Typical failing components in production/container environments:

Redis / distributed cache
Data Protection (Redis or key ring)
OpenIddict certificate loading
Wrong DB connection string

Until you see that exception, the front-end 500/“Failed to load API definition” is just a symptom.

2. Fix Redis / distributed cache configuration (most common cause)

In container / cloud environments, bad Redis configuration will crash application-configuration and Swagger.

In HttpApi.Host’s environment appsettings (for example appsettings.Production.json or the environment you set in ASPNETCORE_ENVIRONMENT), you should have something like:

{
  "Redis": {
    "Configuration": "your-redis-name.redis.cache.windows.net:6380,password=YOUR_PRIMARY_KEY,ssl=True,abortConnect=False"
  },

  "DistributedCache": {
    "KeyPrefix": "Millennial:"
  }
}

Key points:

Use the full Azure Cache for Redis connection string, not just host:port.
Make sure the port is 6380 with ssl=True in Azure.
Apply the same configuration in:
- HttpApi.Host (appsettings.<env>.json)
- DbMigrator (appsettings.<env>.json)
- Any other service using Redis (AuthServer, Background workers, etc.) if present.

If you don’t actually have Redis in the Azure environment yet:

Either provision Azure Cache for Redis and configure as above, or
Disable Redis usage in your solution (remove AbpRedisCache / Redis DataProtection config, and use in‑memory cache for now).

A misconfigured Redis (wrong address or missing password) will usually show errors like:

NOAUTH Authentication required
socket / timeout / connection refused errors to Redis host

These will appear in the API logs right before the 500 on /api/abp/application-configuration.

3. Make sure the environment name matches your appsettings

If your Container App has:

ASPNETCORE_ENVIRONMENT=Production

then the app will use:

appsettings.json
appsettings.Production.json

Common mistakes:

Configured Redis, DB, URLs only in appsettings.Staging.json / appsettings.Development.json, but container runs with Production.
Or vice versa.

Ensure the environment you set in Azure Container Apps matches the file where you placed your production settings.

4. Verify App / Auth URLs for tiered Blazor Server

In the HttpApi.Host appsettings for your deployment environment:

{
  "App": {
    "SelfUrl": "https://<your-api-container-url>"
  },
  "AuthServer": {
    "Authority": "https://<your-auth-server-url-or-api-url>",
    "RequireHttpsMetadata": "true"
  },
  "CorsOrigins": "https://<your-blazor-server-url>,https://<your-public-web-url>"
}

In the Blazor Server appsettings for the same environment:

{
  "RemoteServices": {
    "Default": {
      "BaseUrl": "https://<your-api-container-url>"
    }
  },
  "AuthServer": {
    "Authority": "https://<your-auth-server-url-or-api-url>",
    "RequireHttpsMetadata": "true"
  }
}

Wrong urls typically cause 401/403, not 500, but if some auth/URL‑dependent configuration runs during Application Configuration, it can contribute to failures. Validate them anyway.

5. OpenIddict certificates in containers (if your AuthServer is in the same app)

In containerized / Azure environments, development certificates like AddDevelopmentEncryptionAndSigningCertificate cannot be used reliably. For OpenIddict you should:

In your AuthServer (or the auth-host) module’s PreConfigureServices:

public override void PreConfigureServices(ServiceConfigurationContext context)
{
    var env = context.Services.GetHostingEnvironment();

    if (!env.IsDevelopment())
    {
        PreConfigure<AbpOpenIddictAspNetCoreOptions>(options =>
        {
            options.AddDevelopmentEncryptionAndSigningCertificate = false;
        });

        PreConfigure<OpenIddictServerBuilder>(builder =>
        {
            builder.AddProductionEncryptionAndSigningCertificate(
                "openiddict.pfx",
                Environment.GetEnvironmentVariable("OPENIDDICT_CERT_PASSWORD"));

            // optional: set token lifetimes as needed
        });
    }
}

Then:

Mount openiddict.pfx into the container (volume or file copy at build/publish).
Set the password via an environment variable or Azure secret.

If certificates are misconfigured, you’ll see CryptographicException: Keyset does not exist or similar in logs. That can also result in 500s when the app tries to build application configuration (because auth/validation configuration fails).

6. Summary of what to do right now

Get the HttpApi.Host container logs and find the first exception when hitting /api/abp/application-configuration.
Fix Redis configuration in all appsettings for the deployment environment using the full Azure connection string.
Ensure ASPNETCORE_ENVIRONMENT in Azure matches the appsettings <env> you edited.
Verify App:SelfUrl, AuthServer:Authority, RemoteServices:Default:BaseUrl, and CorsOrigins for your Blazor Server + API + AuthServer.
If using OpenIddict in that environment, use a production PFX certificate rather than development certs.

Once the infrastructure configuration (especially Redis and connection strings) is correct, /api/abp/application-configuration returns 200 and Swagger will load again.

Sources

Application Configuration endpoint reference
(explains the /api/abp/application-configuration API and its role)
https://abp.io/docs/latest

This response was generated by AI. If it didn’t solve your problem, feel free to post a new answer — our support team will jump in to help you soon.

devchase321 created 3 days ago

i already check these possible solutions but it cant work

maliming created 3 days ago

Support Team Fullstack Developer

Can you share the logs.txt of 500 Internal Server Error ?

We need to see what the error is.

Thanks

devchase321 created 3 days ago

I added the logs.txt file to the Google Drive

devchase321 created 3 days ago

Request URL https://api.millennialinformatics.com/api/abp/application-configuration Request Method GET Status Code 500 Internal Server Error Remote Address 20.161.226.4:443 Referrer Policy strict-origin-when-cross-origin

maliming created 3 days ago

Support Team Fullstack Developer

Can you share the full logs.txt with the debug level

https://abp.io/support/questions/8622/How-to-enable-Debug-logs-for-troubleshoot-problems

Thanks

devchase321 created 3 days ago

Please check now, file name: api.millennialinformatics.com.har

maliming created 3 days ago

Support Team Fullstack Developer

Can you share the Logs.txt file?

var loggerConfiguration = new LoggerConfiguration()
    .MinimumLevel.Debug()
    .MinimumLevel.Override("Microsoft.EntityFrameworkCore", LogEventLevel.Warning)
    .Enrich.FromLogContext()
    .WriteTo.Async(c => c.File("Logs/logs.txt"))

Thanks

devchase321 created 3 days ago

Could you please check now - Google Drive for Logs.txt - I wanted to make sure it is the Logs from Azure App

maliming created 3 days ago

Support Team Fullstack Developer

It seems your Redis server is not working.

Can you check that Redis is connectable and working?

Thanks.

devchase321 created 3 days ago

I restarted redis and it is working now - thanks

devchase321 created 3 days ago

Actually it partially resolved issues - I have added more screenshot to the Google Drive - Do you think it is still redis? filename "Error500 Screenshots22"

maliming created 3 days ago

Support Team Fullstack Developer

Please delete the Logs.txt then start your app and reproduce the 500 error and share the Logs.txt again. Thanks.

devchase321 created 3 days ago

Please see it here: https://drive.google.com/file/d/1o2bLhleUmQgq8zZttKxEqFL85Mcm9Npz/view?usp=drive_link

devchase321 created 3 days ago

hi, let me know if you got the latest logs - I am using azure container app for redis

maliming created 3 days ago

Support Team Fullstack Developer

There are no error logs in your latest logs.txt. And the log level is not DEBUG

var loggerConfiguration = new LoggerConfiguration()
    .MinimumLevel.Debug()
    .MinimumLevel.Override("Microsoft.EntityFrameworkCore", LogEventLevel.Warning)
    .Enrich.FromLogContext()
    .WriteTo.Async(c => c.File("Logs/logs.txt"))

devchase321 created 2 days ago

Hi @maliming - please check Google Drive for latest logs 1-28Logs.txt

devchase321 created 2 days ago

Hi, please see the file here: https://drive.google.com/file/d/18lvGQ-s2otEocF51CPTnKRkbJF4REb50/view?usp=drive_link

thanks

maliming created 2 days ago

Support Team Fullstack Developer

The logs show your Redis Server has problem. Can you check and make sure your Redis is working?

Thanks.

devchase321 created 2 days ago

Hi, We have installed fresh Redis (Azure Cache for Redis) and everything seems fine with Redis and other application uses it and runs fine. But the 500 Error issue still persist. I have added latest logs again. Please assist. Thanks

https://drive.google.com/file/d/1FggJACSFaApPeQxrI52VOCLLVrTKOKk9/view?usp=drive_link

devchase321 created 2 days ago

What to do about this: 2026-01-26 03:30:57.531 +00:00 [ERR] The access_token is not active.

2026-01-26 03:30:57.461 +00:00 [DBG] HealthReportCollector - health report execution history saved. 2026-01-26 03:30:57.461 +00:00 [DBG] HealthReport history already exists and is in the same state, updating the values. 2026-01-26 03:30:57.461 +00:00 [DBG] HealthReportCollector has completed. 2026-01-26 03:30:57.461 +00:00 [DBG] HealthCheck collector HostedService executed successfully. 2026-01-26 03:30:57.531 +00:00 [ERR] The access_token is not active. 2026-01-26 03:30:57.532 +00:00 [INF] AuthenticationScheme: Cookies signed out. 2026-01-26 03:30:57.532 +00:00 [INF] Cookies was not authenticated. Failure message: No principal. 2026-01-26 03:30:57.532 +00:00 [INF] Executing endpoint '/Blog' 2026-01-26 03:30:57.532 +00:00 [INF] Route matched with {page = "/Blog", action = "", controller = "", area = ""}. Executing page /Blog 2026-01-26 03:30:57.532 +00:00 [INF] Skipping the execution of current filter as its not the most effective filter implementing the policy Microsoft.AspNetCore.Mvc.ViewFeatures.IAntiforgeryPolicy 2026-01-26 03:30:57.533 +00:00 [INF] Executing handler method Millennial.Web.Public.Pages.BlogModel.OnGetAsync - ModelState is "Valid" 2026-01-26 03:30:57.533 +00:00 [INF] Executed handler method OnGetAsync, returned result . 2026-01-26 03:30:57.533 +00:00 [INF] Executing an implicit handler method - ModelState is "Valid"

maliming created 2 days ago

Support Team Fullstack Developer

Can you remove the existing logs.txt, reproduce the error, and share it again?

The current log file is too big.

Thanks.

devchase321 created yesterday

[devchase321] said: What to do about this: 2026-01-26 03:30:57.531 +00:00 [ERR] The access_token is not active.

2026-01-26 03:30:57.461 +00:00 [DBG] HealthReportCollector - health report execution history saved. 2026-01-26 03:30:57.461 +00:00 [DBG] HealthReport history already exists and is in the same state, updating the values. 2026-01-26 03:30:57.461 +00:00 [DBG] HealthReportCollector has completed. 2026-01-26 03:30:57.461 +00:00 [DBG] HealthCheck collector HostedService executed successfully. 2026-01-26 03:30:57.531 +00:00 [ERR] The access_token is not active. 2026-01-26 03:30:57.532 +00:00 [INF] AuthenticationScheme: Cookies signed out. 2026-01-26 03:30:57.532 +00:00 [INF] Cookies was not authenticated. Failure message: No principal. 2026-01-26 03:30:57.532 +00:00 [INF] Executing endpoint '/Blog' 2026-01-26 03:30:57.532 +00:00 [INF] Route matched with {page = "/Blog", action = "", controller = "", area = ""}. Executing page /Blog 2026-01-26 03:30:57.532 +00:00 [INF] Skipping the execution of current filter as its not the most effective filter implementing the policy Microsoft.AspNetCore.Mvc.ViewFeatures.IAntiforgeryPolicy 2026-01-26 03:30:57.533 +00:00 [INF] Executing handler method Millennial.Web.Public.Pages.BlogModel.OnGetAsync - ModelState is "Valid" 2026-01-26 03:30:57.533 +00:00 [INF] Executed handler method OnGetAsync, returned result . 2026-01-26 03:30:57.533 +00:00 [INF] Executing an implicit handler method - ModelState is "Valid"

Hi i check for redis and rabbit mq its working fine the main issue is when i click login form Public App or Admin App it cant redirect us to auth server and it find login page on Public app url or Admin app url so i cant understand this issue and local is working fine.

And i also uploaded new log file on Google drive

devchase321 created yesterday

And i also uploaded new log file on Google drive

maliming created yesterday

Support Team Fullstack Developer

Volo.Abp.AbpException: Could not find file '~/js/swiper.js'

Please check your js file.

Thanks.
